Optical SiO2 ( Fused Silica IR Grade )
| Refractive Index at ne | 1.4601 |
| Refractive Index, at nF’ nC’ | 0.0068 |
| Refractive Index, at nD | 1.4584 |
| Transmission Range, Refractive index at ne °C-1 for +20°C |
10.10-6 |
| Transmission Range microns (thickness 10MM) | 0.18,3.5 |
| Transmittance ti(l) vs. wavelength l | |
| l,MKM | ti(l) |
|---|---|
| 0.220 | 0.220 |
| 0.230 | 0.435 |
| 0.240 | 0.525 |
| 0.260 | 0.800 |
| 0.270 | 0.930 |
| 0.280 | 0.999 |
| 0.700 | 0.999 |
| 1.000 | 0.999 |
| 1.500 | 0.999 |
| 2.000 | 0.999 |
| 2.720 | 0.999 |
| 2.800 | 0.955 |
| 2.900 | 0.900 |
| 3.000 | 0.870 |
| 3.750 | 0.180 |
| l,MKM | no/ne |
|---|---|
| 0.1700 | 1.615 |
| 0.1850 | 1.575 |
| 0.2000 | 1.550 |
| 0.2144 | 1.5337 |
| 0.2803 | 1.4940 |
| 1.3021 | 1.4872 |
| 0.3650 | 1.4745 |
| 0.4046 | 1.4696 |
| 0.4358 | 1.4666 |
| 0.5461 | 1.4601 |
| 0.5876 | 1.4585 |
| 0.5893 | 1.4584 |
| 0.6438 | 1.4567 |
| 0.6563 | 1.4564 |
| 0.8621 | 1.4525 |
| 1.0830 | 1.4494 |
| 1.3950 | 1.4458 |
| 1.7091 | 1.4421 |
| 2.0581 | 1.4372 |
| 3.2439 | 1.4131 |
| Thermal Linear Expansion at, °C-1 for 0,+50°C | 4.0 . 10-6 |
| Thermal Conductivity W/(m .°C) at 20 °C | 1.35 |
| Specific Heat Capacity, J/(kg .°C) | 728.0 |
| Melting Point, °C | 1900 |
| Density, g/cm3 at 20 °C | 2.21 |
| Poisson Ratio | 0.17 |
| Young Modulus (E), Pa | 7.36 . 1010 |
| Shear Modulus (G), Pa | 3.14 . 1010 |
| in water | in acids |
|---|---|
| insoluble | insoluble |
